Autoturners Automations Pvt. Ltd.

Model No.	ALP-25	ALP-32	ALP-42	AL-50	AL-60
Max. Capacity Round Bar	25 mm	32 mm	42 mm	50 mm	60 mm
Hexagonal	22 mm AF	25 mm AF	36 mm AF	42 mm AF	52 mm AF
Square	18 mm	22 mm	29 mm	36 mm	42 mm
Max. Turning Length With Long Turning Attachment	50 mm	60 mm	65 mm	70 mm	75 mm
Maximum Drill	40 mm	50 mm	60 mm	70 mm	70 mm
Spindle Speed (6)	690-2160	690-2160	440-1350	2	2
Production Rate in Pieces Per Hour	22-794	22-794	14-529	14-529	14-529
Electric Drive Motor	2 HP	3 HP	5 HP	5 HP	5 HP
3 Phase	1400 RPM	1400 RPM	900 RPM	900 RPM	900 RPM

Standard Accessories : Front & Rear Main Slides, Drill Slide, One Vertical Slide, Stop Bar, One Collet One Drill Holding Plunger with Collet, Electric Drive Motor, Coolant Pump, One Set of Cams, Bar Feed, One Set of Tool Holders.
Additional Accessories : Rear Vertical Slide, Long Turning Attachment (Front & Rear), Feed Change Gear Box with 30 Feeds. Various Types of Tool Holders, Cams, Collets, Chamfering Tool Holder, Knee Tool Holder.
