| Capacity | - | ATR 200 | ATR 300 | ATR 350 |
| Swing Over Bed | mm | 450 | 500 | 500 |
| Max Turning Dia. (Upto) | mm | 250 | 300 | 300 |
| Standard Turning Dia | mm | 200 | 250 | 250/300 |
| Max Turning Length (Chuck Face) | mm | 500 | 750 | 1000 |
| Admit Between Centers | mm | 600 | 850 | 1100 |
| Chuck Size | mm | 200 | 250 | 250/300 |
| Main Spindle | ||||
| Spindle Nose | - | A2-6 | A2-6 | A2-6/A2-8 |
| Spindle Power | kw | 7.5/11 | 7.5/11 | 11/15 |
| Spindle Speed | RPM | 3000 | 2500 | 2500 |
| Bore Through Drawbar | mm | 52 | 52 | 52/72 |
| Feed Rates | ||||
| Rapid Traverse X-Axis | mt/min | 20 | 20 | 20 |
| Rapid Traverse Z-Axis | mt/min | 20 | 20 | 20 |
| Tail Stock | ||||
| Quill Dia./Stroke | mm | 70 | 70 | 100 |
| Quill Taper | No. | MT4 | MT4 | MT4 |
| Quill Travel | mm | 100 | 100 | 100 |
| Turret/Tooling | ||||
| Size (Model) | BTP | 80 | 80 | 80/100 |
| No. Of Tool Positions | No. | 8 | 8 | 8 |
| Tool Shank Size | mm | 25x25 | 25x25 | 25x25 |
| Max Boring Bar Dia | mm | 40 | 40 | 40 |
| CNC System | Make | Fanuc/Siemens/Delta | Fanuc/Siemens/Delta | Fanuc/Siemens/Delta |
| Accuracy | ||||
| Positioning Accuracy | mm | ±0.003 | ±0.003 | ±0.003 |
| Repeatability | mm | ±0.004 | ±0.004 | ±0.004 |
| Parameters | ||||
| Overall Size (LxBxH) | mm | 2500x1500x1800 | 2600x1575x1900 | 3000x1600x2000 |
| Machine Weight (Approx) | kg | 3000 | 3500 | 4000 |
